HP DesignJet T230 24' A1 Graphics Large Format Inkjet Printer (5HB07D)

This product fits   in your saved printer list.

Our Price:

In Stock
$
989
.00

What is Rewards Points?

Earn reward points every time you shop at InkStation. For every dollar you spend on products, you'll earn 1 point. Once you collect 200 points, you can redeem them for a $1 voucher—or save up 1,000 points to get a $5 voucher.

The more you purchase, the more rewards points you earn, so start earning today and enjoy discounts on your next order.

Learn More.

Earn
1978
Rewards Points
Always competitive price

Double Rewards Points

Qty:

This item is excluded from the free delivery offer. Additional shipping fees apply to large and bulky items due to their size and weight.

For more information, see our Shipping Policy Page.

 Delivery charges may apply
Shipping Calculator Postcode

Product Summary:

  • 24" (A1) large format printer
  • Max resolution 2400 x 1200 dpi
  • Print speeds up to 35 sec per A1/D plot
  • Pigment inks - Black Dye-ink - Cyan, Magenta, Yellow
  • Print with HP Click software and Smart app
  • Connectivity: Wi-Fi / Ethernet / USB

Printers & Scanners Double Rewards PointsOffer valid on Printers & Scanners. Rewards apply to InkStation Rewards members only.

InkStation Rewards Program terms and conditions apply. Offer ends 30/06/2026.

Accessories
$124.70 $124.70
$477.97 $477.97
$192.25 $192.25
HP Cartridges
$239.22 $239.22

SKU: STU29794

You May Also Like

Description:

Overview:

Designed to fit your office, budget, and the way you work, the world's smallest plotters provide outstanding simplicity. Send multiple files in just one click. Print your A1/D plot as fast as 35 seconds. 512 MB memory. AEC, GIS, and MCAD professionals who want to print maps, technical drawings, posters, and renders with precise, accurate line quality and crisp text. Print easily and affordably with the world's smallest wide format printer. Impressive simplicity helps you save time and reduces waste. Use up to 95% less ink for routine maintenance. Be efficient and productive from job prep to final print. Dynamic security enabled printer. Only intended to be used with cartridges using an original HP chip.



Features:

  • This is a large format printer, capable of producing A1 posters, photos, and more.
  • Print only

  • High-speed printing - As fast as 35 seconds per A1/D plot.

  • Interfaces - USB, Ethernet, Wi-Fi
  • The printer has a maximum print resolution of 2400 x 1200 dpi.
  • Extreme simplicity - Easy to use with an intuitive driver and true print preview.
  • Print multi-size projects automatically from A1/D to A4/A with an auto sheet feeder, without manually switching media.

  • HP Click software - Send multiple files for prints in one click.

  • HP Smart app - Print your jobs and manage your plotter from virtually anywhere.

  • Get high-quality results and improved line accuracy with a 34% enhanced colour gamut..

  • Save energy with automatic on/off and efficient ink maintenance. Made with up to 40% recycled plastic.

Product Info

Sku: 5HB07D

Product type: Office Printers for CAD and GIS

Series: Designjet

Functions: Print only

Print technology: HP Thermal Inkjet

Duplex printing: Not Applicable

Connectivity, standard: Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct

Number of print cartridges: 4 (C, M, Y, K)

Ink types: Dye-based (C, M, Y); pigment-based (K)

Colour(s) of printing supplies: Cyan, magenta, yellow, black

Print head nozzles: 1376

Print heads: 1 (cyan, magenta, yellow, black)

Number of print cartridges: 4 (C, M, Y, K)

Ink types: Dye-based (C, M, Y); pigment-based (K)

Finished output handling: Sheet feed, roll feed, automatic horizontal cutter

Print quality colour (best): Up to 2400 x 1200 optimised dpi

Media sizes supported: A4, A3, A2, A1

Media sizes, custom: 210 x 279 to 610 x 1897 mm

Media types: Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene)

Media weight, recommended: 60 to 280 g/m²

Memory: 512 MB

Power Consumption Description: <35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (standby)

Warranty: One-year limited hardware warranty



What's in the box?

HP DesignJet T230 24-in Printer, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord


Please noted: USB cable is NOT included.



Download Datasheet



Show More
Specification:

General

Brand
HP
Applications
Line drawings; Presentations; Renderings
Manufacturer Warranty
12 Months
Model Number
5HB07D
Paper Size
A1
Printing Output Type
Colour
Printing Technology
Thermal Ink-Jet
Product Dimensions
1013x440x285 mm
Product Weight
21.5 kg
USB Cable Included
no

Connectivity

Interface
USB, Ethernet & Wi-Fi
Printing Software Utilities
HP Click, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant

Media Handling

Media Handling
Sheet feed, roll feed, automatic horizontal cutter
Media Thickness
up to 0.3mm
Media Width
279 - 610 mm
Grammage
60 to 280 g/m²
Standard sheets
A4, A3, A2, A1

Printer Performance

Print Speed
35 sec/page on A1, 68 A1 prints per hour
Print Resolution
2400x1200 dpi
Line Accuracy
±0.1%
Number of Nozzles
1376
Ink Drop
5.5 pl (C, M, Y); 12 pl (K)

Refilling

Refills
HP 712/712B
Ink Type
Dye-based (Cyan, Magenta, Yellow); pigment-based (Black)

Package Contents

T230 24" Printer
1
Accessories
Printhead, introductory ink cartridges, spindle, setup poster
Quick Reference Guide
1
Power Cord
1
Show More
